PARTS LIST
5-9
Model C152 & C161
Parts List
5
Model C15227H000, 208-230V 60HZ 1PH A/C Tecumseh (R404A)
Description Part Number Qty. Warr. Class Comments
Block-Terminal 2P L1,L2 039422 1 103
Board-Power GEN 1 & 2 X69574-SER 1 212
+Fuse-.063A-250V-5X20MM-SLO B 051272 1 000
Compressor AKA9462ZXD-AK172ET 049302-27 1 512
+Capacitor-Run-15UF/370V 027087 1 103
+Capacitor-Start-72 88UF/330 039567 1 103
+Relay-Start-Compressor 048150 1 103
Compressor TL3G- R134A 047701-27 1 512 Aux - May Use X47701SER2 Complete Kit
+Relay-Start-Compressor TL3G 047702-27 1 103
+Capacitor-Start-60UF-220/275V 047703 1 103
+Dryer-Cap. Tube .026 ID x 8F 048725 1 000
Contactor 230VAC 1PH 50/60HZ 055248-27 1 103
Cord-Power 025340-27 1 103
Diagram-Wiring *C152* 086047-27 1 000
Harness-Trans Relay A. 086256-27 1 103
Kit A.-Motor-Fan X62253-27 1 103
Motor-1/2 Hp 059742-27 1 212
+Capacitor-Run 30MFD/370V 083338 1 103
+Capacitor-Start 130-156UF/330V 083339 1 103
+Screw-5/16-18x5/8 SERR. F 017973 4 000
Motor-Fan 95.3 CFM 2700 RPM 062253-27 * 103 See - Kit A.-Motor-Fan
Motor-Fan 027817-27 1 103
+Fan 4 Blade 11 " Push 30 Deg CW 027818 1 103
Relay-3 Pole-30A-208/240 50/60 066795-33 1 103
