Taylor c713 Original Operating Instructions

Model C713 Table of Contents
Table of Contents
Section 1 To the Installer 1............................................
Installer Safety 1........................................................
Site Preparation 1.......................................................
Air Cooled Units 1.......................................................
Water Connections (Water Cooled Units Only) 2...........................
Electrical Connections 2.................................................
Beater Rotation 3.......................................................
Refrigerant 3...........................................................
Section 2 To the Operator 4...........................................
Section 3 Safety 5....................................................
Section 4 Operator Parts Identificatio n 7...............................
Model C713 7..........................................................
Door and Beater Assembly 9.............................................
Accessories 10..........................................................
Brushes 11..............................................................
Section 5 Important: To the Operator 12.................................
Symbol Definitions 13....................................................
Operating Screen Descriptions 15..........................................
Manager's Menu 16......................................................
Section 6 Operating Procedures 21.....................................
Freezing Cylinder Assembly 21............................................
Sanitizing 26............................................................
Priming 27..............................................................

Taylor c713 Specifications

General

Type	Soft Serve Freezer
Number of Flavors	2
Refrigeration System	Air or Water Cooled
Separate Hopper Refrigeration	Yes
Indicator Lights	Yes
Water Cooled	Yes
Electrical	208-230V, 1PH, 50/60Hz
Motor	Two 1.5 HP
Air Cooled Minimum Clearance	6" on both sides
