Taylor c713 Service Manual

4-30
PARTS
Models C712/C713
Parts
4
Brushes (Model C712 & C713)
Figure 4-20
6
7
5
4
1
2
3
Item Description Part No.
1 Brush-Rear BRG 1"D x 2"LG 013071
2 Brush-Dbl End-Pump & Feed
Tube
013072
3 Brush-Draw Valve 1"OD x 2"x1 014753
4 Brush-Mix Pump Body-3" x 7" 023316
Item Description Part No.
5 Brush-End-Door-Spout-SS 039719
6 Brush-Set LVB 050103
7 Brush-Pump Spout 054068

Taylor c713 Specifications

General

Type	Soft Serve Freezer
Number of Flavors	2
Refrigeration System	Air or Water Cooled
Separate Hopper Refrigeration	Yes
Indicator Lights	Yes
Water Cooled	Yes
Electrical	208-230V, 1PH, 50/60Hz
Motor	Two 1.5 HP
Air Cooled Minimum Clearance	6" on both sides
