Taylor C723 Service Manual

27
Model C723
Controls, Systems and Operations
Pressing the SEL key with the cursor next to
“START” will bring up the Start screen. Pressing the
SEL key will start the component and run it until the
SEL key is pressed again. Pressing the SEL key
with the cursor next to “Exit” will return the screen to
the Manual Control Menu.
Software Update
This option allows the service technician to update
the machine's firmware. The following screen will
display. (See Figure 56.)
SOFTWARE UPDATE
ARE YOU SURE?
>Yes
No
Figure 56
Pressing the UP arrow key moves the arrow to
“Yes”. Pressing the SEL key will begin the update
process. Pressing the SEL key with the arrow next
to “No” cancels the update and returns to the
Service Menu screen.
Reset to Defaults
The Reset to Defaults option allows the service
technician to load the system defaults into
ferromagnetic (FRAM) memory. (See Figure 57.)
RESET TO DEFAULT
ARE YOU SURE?
>Yes
No
Figure 57
Pressing the UP arrow key moves the arrow to
“Yes”. Pressing the DOWN arrow key moves the
arrow to “No”. Pressing the SEL key with the arrow
next to “Yes” corrupts FRAM and then restarts the
CPU, which then loads the default values into FRAM
during memory initialization. Pressing the SEL key
with the cursor next to “No” has no effect and
returns the display to the Service Menu screen.

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
