Taylor C723 Service Manual

+ Available Separately
72
Parts List Model C723
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
HARNESS-WIRE-MAIN POWER *C723* 069083-27G 1 103 208-230V 60HZ 1PH
HARNESS-WIRE-MAIN POWER *C723* 069083-33G 1 103 208-230V 60HZ 3PH
HARNESS-WIRE-MIX LVL *C723* 068873 1 103
INTERLOCK A.-DOOR X65658 1 103
SWITCH-REED*DOOR INTERLOCK*68" 056771 1 103
JACK A.-FLAVORBURST X56353 2 103
KIT A.-DANFOSS *GENERAL* X48314SER2 1 512
+COMPRESSOR TL3G-R134A 047701-27 1 512
+CAPACITOR-START 60UF-220/275V 047703 1 103
+COVER-TERMINAL-COMPRESSOR 047739 1 103
+DRYER-CAP. TUBE .026ID X 13FT 047699 1 000
+KIT-MOUNTING-COMPRESSOR 047704 1 000
+RELAY-START-COMPRESSOR-TL3G 047702-27 1 103
KIT A.-MOTOR-FAN X62253-27 1 103
KIT A.-PROBE-THERMISTOR IP68 X82397-SER 4 103 M4033913 & UP REPLACES 038061-BLK
KIT A.-TUNE UP-3 SPT C713 X49463-80 1 000
BEARING-FRONT 050216 2 000
CAP-DESIGN 1.010"ID-6 POINT 014218 3 000
GASKET-DOOR HT 4"-DOUBLE 048926 2 000
O-RING-.643 OD X .077W 018572 8 000
O-RING-1/2OD X .070W 024278 4 000
O-RING-3/8 OD X .070W 016137 2 000
O-RING-7/8 OD X .103W 014402 6 000
SEAL-DRAW VALVE 034698 1 000
SEAL-DRIVE SHAFT 032560 2 000
TOOL-O-RING REMOVAL-FREEZER 048260-WHT 1 000
LABEL-3PH MTR PROT/1PH C- 025949 1 000 208-230V 60HZ 3PH
LABEL-CAUTION-GRD-PERM-ENG/SP 032164 1 000
LABEL-CK MTR ROTATE-CW-ENG/SPN 020090 1 000 208-230V 60HZ 3PH
LABEL-DOOR-MOVE PART 032749 1 000
LABEL-SW-POWER-OFF/ON-SYMBOLS 052632 1 000
LABEL-WARN-COVER 051433 5 000

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
