71
+ Available Separately
Model C723 Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
FASTENER-CLIP 1/4-20 U-TYPE 045865 14 000
FASTENER-DOOR LATCH 030787 2 000 LOWER PANEL 10/25/10 To 4/29/13
FASTENER-DOOR STRIKE 030788 2 000 LOWER PANEL 10/25/10 To 4/29/13
FILTER A.-*C723* X81440 1 103 S/N M3044207 COMPLETE WITH FRAME AND FILTER
FILTER-AIR-18.28X15.5X.70 052779-15 1 000 S/N M3044207 & UP - FILTER ONLY
FILTER-AIR-21.688X15.813HX.70W 052779-9 1 000 S/N M3044206 & PRIOR
FILTER-CORCOM 6EH1 040140-001 1 103 UPPER CONTROL
FUSE-BUSS-ABC-15-R ROHS COMP 076414 2 000 S/N M2035082 & UP REPLACES 045293/045606
+FUSE A.-HOLDER-INLINE X69221 2 000 S/N M2035082 & UP
FORM-QUALITY REPORT BY FAX 065712 1 000
GASKET-BASE PAN *C723* 068776 1 000
+SCREW-10X7/16 UNSL TD HWH 066234 12 000 PAN GASKET
GASKET-DOOR HT 4"-DOUBLE 048926 2 000
GEAR A.*REDUCER 4.21:1 SERVICE 021286SER1 2 212 12/7/15 REPLACED 021286-SER
+SCREW-5/16-18X3-1/4 HEX HEAD 022678 8 000 GEAR
GUARD-POWER SWITCH 034830 1 103
GUIDE A.-DRIP PAN *338* X51567 1 103
GUIDE-DRIP PAN 068932 2 103
GUIDE-DRIP SEAL 028992 2 000
GUIDE-FILTER-LEFT *C722/C 081836 1 103 S/N M3044207 & UP
GUIDE-FILTER-RIGHT *C722/ 081837 1 103 S/N M3044207 & UP
GUIDE-FILTER-LEFT *C708/C709* 056941 1 103 S/N M3044206 & PRIOR
GUIDE-FILTER-RIGHT *C708/C709* 056943 1 103 S/N M3044206 & PRIOR
HARNESS-WIRE-BTR MTR *C723* L 068915-27L 1 103 208-230V 60HZ 1PH
HARNESS-WIRE-BTR MTR *C723* R 068915-27R 1 103 208-230V 60HZ 1PH
HARNESS-WIRE-BTR MTR *C723* 068915-33L 1 103 208-230V 60HZ 3PH
HARNESS-WIRE-BTR MTR *C723* 068915-33R 1 103 208-230V 60HZ 3PH
HARNESS-WIRE-CAP/RELAY BOX 069079-27G 1 103 208-230V 60HZ 1PH
HARNESS-WIRE-COMP *C723* 069079-33G 1 103 208-230V 60HZ 3PH
HARNESS-WIRE-CNTRL *C723* 068874 1 103 UPPER CONTROL
HARNESS-WIRE-DANFOSS *C723* 081309-27 1 103
HARNESS-WIRE-LW V-CNTL*C723* 068917 1 103 LOWER CONTROL
To Next Page
