Taylor C723 Service Manual

+ Available Separately
70
Parts List Model C723
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
CONTROL-ROHS-HT INTF BASE-UK 063920-SER 2 212 REPLACES X63920-SER PCB & X40799-SER CHIP
PCB A.-ROHS-PERSONALITY-HT-SS 063922-SER 2 212
COUPLING-3/8FS X 1/4FS 031791 3 103
COUPLING-DRIVE 3/4 HEX X 1-7/8 012721 2 103
COVER-ACCESS-LEFT *C723* 081834 1 103 S/N M3053200 & UP REPLACED 068869
COVER-ACCESS-FRONT-R. *C708* 056933 1 103 REPLACED 081833 10/27/14
COVER-CAP&RELAY *C723* 068850 1 103 208-230V 60HZ 1PH
COVER-HOPPER-14 QT-BLACK 041682-BLA 2 103
DECAL-DOOR-3 SPOUT-TWIN TWIST 062239 1 000
DECAL-INST-CLN HPR 019029 1 000
DECAL-TROUBLESHOOT 038374 1 000
DIAGRAM-WIRING *C723* 068807-27 1 000 208-230V 60HZ 1PH
DIAGRAM-WIRING *C723* 068807-33 1 000 208-230V 60HZ 3PH
DOOR A.-*SH BAF*W/PRG *C723* X68889-SER 1 103
BAFFLE A.-SHORT 4 IN W/RAD THD X50883 2 103
+FRONT BEARING 050216 2 000
+GASKET-DOOR HT 4"-DOUBLE 048926 2 000
+HANDLE A.-DRAW *C602*C606* X56421-1 3 103
+O-RING-1/4 OD X .070W 50 DURO 015872 3 000
+SCREW-ADJUSTMENT-5/16-24 *602* 056332 3 103
+PIN-HANDLE-TWIN *C712/C717* 059894 1 103
+PLUG-PRIME TWIN *C712/C713* 059936 2 103
+O-RING-1/2OD X .070W 024278 4 000
+VALVE A.-DRAW *C712/C713* X69615 2 103 S/N M1123969 & UP - REPLACES X59843 & 014402
+O-RING-7/8 OD X .103W-SIL 083693 4 000 REPLACED 019330 6/26/15
+VALVE A.-DRAW-CENTER X62218 1 103
+SEAL-DRAW VALVE *LARGE H-RING* 034698 1 000
+O-RING-7/8 OD X .103W-SIL 083693 4 000 REPLACED 019330 6/26/15
DRYER-CAP. TUBE .026ID X 13F 047699 1 000
DRYER-FILTER-HP62-3/8 X 1/4S 048901 1 000
EYELET-RESET BUTTON 013739 2 103
FASTENER-CLIP-FAST LEAD U 081583 2 000

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
