Taylor C723 Service Manual

69
+ Available Separately
Model C723 Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
BUSHING-SNAP 11/16 ID X 7/8OD 010548 1 103
BUSHING-SNAP 1-5/8ID X 2 OD 043637 4 103
BUSHING-SNAP 15/16 ID X 1-3/32 023396 1 103
BUSHING-SPLIT 43/64ID X 7/8OD 027691 1 103 MAIN COMP
CABLE-CONTROL/INTERFACE * 069023 1 103 S/N M1063856 & UP - REPLACED 069024
CABLE-RIBBON-14C-3"L-SIL/SIL 056864 1 103 DEC PLATE
CABLE-RIBBON-50C-20"L-DIL/DIL 040040-011 1 103
CABLE-RIBBON-20C-17"L-DIL/DILR 040040-013 1 103
CABLE-RIBBON-50C-25"L.DIL/DIL 040040-025 1 103
CABLE-RIBBON-20C-14"L-DIL/DIL 040040-040 1 103
CABLE-RIBBON-20C-16"L-DIL/DIL 040040-049 1 103
CABLE-USB 056785 * 103 S/N M1063855 & PRIOR TO UVC4
CABLE-CONTROL/INTERFACE A 069024 * 103 S/N M1063855 & PRIOR TO UVC4
CAP-DESIGN 1.010"ID-6 POINT 014218 3 000
COMPRESSOR TL3G-R134A 047701-27 1 512 **SEE KIT X48314-27
+CAPACITOR-START 60UF-220/275V 047703 1 103
+RELAY-START-COMPRESSOR-TL3G 047702-27 1 103
COMPRESSOR L64A113BBCA 048259-27E 1 512 208-230V 60HZ 1PH
+CAPACITOR-RUN 25UF/440V 037431 1 103
+CAPACITOR-START 189-227UF/330V 033044-1 1 103
+RELAY-START-COMPRESSOR 062363 1 103
+SCREW-5/16-18X1-1/2 HEX HEAD 001894 4 000
+SLEEVE-MOUNTING-COMP. 039924 4 000
+GROMMET-COMPRESSOR MOUNTING 037428 4 000
COMPRESSOR L63A113DBLA 048259-33 1 512 208-230V 60HZ 3PH
+SCREW-5/16-18X1-1/2 HEX HEAD 001894 4 000
+SLEEVE-MOUNTING-COMP. 039924 4 000
+GROMMET-COMPRESSOR MOUNTING 037428 4 000
CONDENSER-AC 16X16 3ROW 14FPI 056944 1 103 FAN MOTOR
CONDENSER-AC 7X6X1.25-2 ROW 027155 1 103
CONTROL-ROHS-INTF*C712-C717* 063925-SER 1 212 DEC PLATE
CONTROL-INTERFCE-HT-SS-UK ROHS 063964-SER 2 212 LOWER CONTROL-REPLACES X63964-SER

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
