Taylor C723 Service Manual

Parts List
+ Available Separately
68
Parts List Model C723 160205
DESCRIPTION PART
NUMBER
QTY. WARR.
CLASS
REMARKS
C72327FW00 & C72333FW00 - 208-230V 60HZ 1PH & 208-230V 60-HZ 3 PH A/C-BRISTOL (R404A) - ROHS COMPLIANT
ACCUMULATOR-COPPER 2"DIA 10"LG 047062 1 103
ACTUATOR A.-DRAW SWITCH * X69835 1 103 S/N M1116244 & UP REPLACES X62401
ARM-DRAW SWITCH-LEFT 069166 1 103
ARM-DRAW SWITCH-RIGHT 069167 1 103
BRACKET A.-SPRING-RETURN X69481 1 103
BRACKET A.-SWITCH *C71X* X69836 1 103
E-RING 1/4 BLACK PHOS 032190 3 000
PIN-PIVOT-DRAW SWITCH 038484 1 103
ROD-SPRING RETAINER 038254-SP 1 103
SCREW-ADJUSTMENT-DRAW PADDLE 069374 2 000
SPRING-EXTENSION.467X.062X1. 069392 2 103
SPRING-RETURN-LEFT-TWIN TWIS 038923 1 103
SPRING-RETURN-RIGHT-TWIN TWI 038924 1 103
ACTUATOR A.-DRAW SWITCH X62401 * 103 S/N M1116243 & PRIOR
BEARING FRONT 050216 2 000
BEARING-REAR SHELL-NICKEL 031324 2 000
+GUIDE-DRIP SEAL 028992 2 000
+NUT-BEARING 028991 2 000
+WASHER-BEARING LOCK 012864 2 000
BEATER A.-2.8QT-HELICORE X35466 2 103
+BLADE-SCRAPER-PLASTIC 13-1/4L 035480 4 000
BELT-AX37 RIGHT 023447 2 000 RIGHT M3044471 - PRIOR USED 4 - 022848
BELT-AX35 LEFT 022848 2 000 LEFT M3044471 USE 2-022848 AND 2-023447
BLOCK-TERMINAL 2P L1,L2 039422 1 103 208-230V 60HZ 1PH - SPLICE BOX
BLOCK-TERMINAL 3P L1,L2,L3 039423 1 103 208-230V 60HZ 3PH
BRUSH-REAR BRG 1"D X 2"LG X 14 013071 1 000
BRUSH-DBL END-PUMP & FEED TUBE 013072 1 000
BRUSH-DRAW VALVE 1"OD X 2"X17" 013073 1 000
BRUSH-MIX PUMP BODY-3" X 7" WH 023316 1 000

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
