Taylor C723 Service Manual

+ Available Separately
76
Parts List Model C723
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
VALVE-ACCESS-1/4MFL X 3/8ODSDR 053565 4 103 LINE A.-DISCHARGE *C723*
+CAP-VALVE-ACCESS 9/16 HEX 054518 4 000
+CAP-VALVE-ACCESS 13/16 HEX 054519 4 000
VALVE-EPR 1/4S 022665 1 103 LINE A.-DANFOSS *C723*
VALVE-EXP-AUTO-1/4S X1/4 FPT 046365 2 103
+BOOT-VALVE-EXPANSION 050900 2 000
VALVE-SOLENOID 7/16 ORF 5/8ODF 048626-27 2 103 S/N M2016590 & UP
+BOOT-INSULATING-VALVE-SOL SUCT 080523 2 103 S/N M2125026 & UP
VALVE-SOLENOID 1/2ORF X 5 069559-27 * 103 S/N M1117098 THRU M2016589
VALVE-SOLENOID 7/64ORF X 1/4S 043449-27 2 103 LINE A.-LIQUID *C723*
WATER COOLED
ACCUMULATOR-COPPER 2"DIA 13" 053377 1 103
BRACKET-CAP/RELAY *C723* 069175 1 103
CONDENSER-WC-SPIRAL 11-1/ 049309 1 103
COVER-ACCESS *C723*WC 069196 1 103
FAN-5 BLADE 10 " PUSH 013043 1 103
LABEL-INLET 037288 1 000
MOTOR-FAN-25W 230V 015184-27 1 103
+BRACKET-FAN *453/750* 038641 1 103
PANEL-REAR *C723*WC 069171 1 103
PANEL-SIDE-RIGHT *C723*WC 069170 1 103
SWITCH-PRESSURE 350 PSI-S 048231 1 103
VALVE-WATER 3/8 REG/HEAD PRE 046686 1 103
+BRACKET A.-FITTING*C706/C707 X64145-SP2 1 103
50 HZ
BLOCK-TERMINAL 3P L1,L2,L 039423 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
BLOCK-TERMINAL 4 POLE GRE 080967 3 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 220-240V 50HZ 1PH -
380-415V 50HZ 3N~(4WIRE)
BLOCK-TERMINAL 3 POLE GRE 080968 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 220-240V 50HZ 1PH -
380-415V 50HZ 3N~(4WIRE)

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
