Taylor C723 Service Manual

77
+ Available Separately
Model C723 Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
+PLATE-END TERMINAL BLOCK 080969 2 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 220-240V 50HZ 1PH -
380-415V 50HZ 3N~(4WIRE)
BLOCK-TERMINAL 2P L1,N 039421 1 103 220-240V 50HZ 1PH
BLOCK-TERMINAL 4P L1,L2,L 039424 1 103 380-415V 50HZ 3N~(4WIRE)
CAPACITOR A.-RF X58666 1 000 220-240V 50HZ 1PH
COMPRESSOR L63A113DBLA 048259-33 1 512 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
COMPRESSOR L63A113BBKA 048259-40 1 512 220-240V 50HZ 1PH
COMPRESSOR L63A113DBEA 048259-58 1 512 380-415V 50HZ 3N~(4WIRE)
+CAPACITOR-RUN 25UF/370VAC 023739 1 103 220-240V 50HZ 1PH
+CAPACITOR-START 161-193UF 031790 1 103 220-240V 50HZ 1PH
+RELAY-START-COMPRESSOR 038146 1 103 220-240V 50HZ 1PH
DIAGRAM-WIRING *C723* 068807-39 1 000 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
DIAGRAM-WIRING *C723* 068807-40 1 000 220-240V 50HZ 1PH
DIAGRAM-WIRING *C723* 068807-58 1 000 380-415V 50HZ 3N~(4WIRE)
HARNESS-WIRE-BTR MTR *C72 068915-33L 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 380-415V 50HZ
3N~(4WIRE)
HARNESS-WIRE-BTR MTR *C72 068915-33R 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 380-415V 50HZ
3N~(4WIRE)
HARNESS-WIRE-CAP/RELAY BO 069079-40 1 103 220-240V 50HZ 1PH
HARNESS-WIRE-CNTRL *C723* 068874-G 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 220-240V 50HZ 1PH
HARNESS-WIRE-COMP *C723* 069079-33G 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 380-415V 50HZ
3N~(4WIRE)
HARNESS-WIRE-DANFOSS *C72 081309-27G 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 220-240V 50HZ 1PH -
380-415V 50HZ 3N~(4WIRE)
HARNESS-WIRE-MAIN POWER * 069083-33G 1 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
HARNESS-WIRE-MAIN POWER * 069083-40G 1 103 220-240V 50HZ 1PH
HARNESS-WIRE-MAIN POWER * 069083-58G 1 103 380-415V 50HZ 3N~(4WIRE)
MOTOR-1.0 HP 013102-33 2 212 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
MOTOR-1.0 HP 013102-34 2 212 220-240V 50HZ 1PH
MOTOR-1.0 HP 013102-35 2 212 380-415V 50HZ 3N~(4WIRE)
LABEL-CK MTR ROTATE-CW-EN 020090 1 000 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 380-415V 50HZ
3N~(4WIRE)

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
