Taylor C723 Service Manual

+ Available Separately
78
Parts List Model C723
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
LABEL-3PH MTR PROT/1PH C- 025949 1 000 220-240 50 HZ 3PH - 200V 50/60HZ 3PH - 380-415V 50HZ
3N~(4WIRE)
PULLEY-2AK25 X .6255-.626 021076 2 103 220-240V 50HZ 1PH - 380-415V 50HZ 3N~(4WIRE)
STARTER-3 PHASE 2.5 TO 4 066794-33H 2 103 220-240 50 HZ 3PH - 200V 50/60HZ 3PH
STARTER-3 PHASE 1.6 TO 2. 2 103 380-415V 50HZ 3N~(4WIRE)
ADJUSTABLE FEED TUBE
TUBE A.-FEED-INNER-AIR/MI X67103 2 103
TUBE A.-FEED-OUTER-HT X67104 2 103
+O-RING-.291 ID X .080W 018550 6 000
+O-RING-.643 OD X .077W 018572 4 000
KIT A.-TUNE UP-3 SPT C713 X49463-80A 1 000
C72327FWBE - ROHS COMPLIANT-HOPPER AGITATOR
BLADE A.-AGITATOR *794* X56591-SP 2 103
HARNESS-WIRE-MIX LVL *C72 068873 1 103
HOUSING A.-AGITATOR *C708* X56586-03 2 103
BODY-AGITATOR HOUSING *C708* 056588 2 103
CAP-AGITATOR HOUSING 080827 2 103 S/N M2044359 & UP - REPLACED 056589
O-RING-1-3/8 OD X .070W 017395 2 000
MAGNET A.-AGITATOR-INNER 066937 1 103
MAGNET A.-AGITATOR*C708* X57341 2 103
SCREW-8-32X3/16 SOCKET SET 006812 2 000
MOTOR-AGITATOR-24VAC 50/60 H 050535-03 2 103
PLATE-HOLDING-AGITATOR *C708 056587 2 103
+CAPACITOR-MOTOR-AGITATOR 057525 2 103
SCREW-4-40X1/4 SOCKET HEAD 600165 4 000
LABEL-CAUTION-AGITATOR 045191 2 000
SHELL A.-INSULATED *C723* X68775-SER 1 512
STUD-NOSE CONE *C602* 055987 4 103
TRANS.-120/208/240V PRI 2 051660 1 103

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
