OPERATOR PARTS IDENTIFICATION
Model C723
Operator Parts Identification
4
Model C723 Exploded View Parts Identification
Item Description Part No.
1 Cover-Hopper 041682-BLA
2 Orifice 022465-100
3 O-ring-3/8 OD X .070W
(100 to Bag)
016137
4 Tube A.-Feed-SS-5/32 Hole X29429-2
5 O-ring-.643 OD X .077W
(50 to Bag)
018572
6 Panel-Rear 069340
7 Panel A.-Side Right X68854
8 Panel A.-Front X81843
9 Screw-1/4-20X3/8 SLTD 011694
10 Panel A.-Shelf
(Includes Items 10a -10c)
X81840
10a Panel A.-Front-Lower X81841
10b Shelf-Drip Tray 080782
Item Description Part No.
10c Screw-1/4-20X3/8 SLTD 011694
11 Screw-Wing Head 081582
12 Tray-Drip 080781
13 Shield-Splash-Wire 046177-SP
14 Pan A.-Drip 15 1/8 Long X51601
15 Stud-Nose Cone 055987
16 Panel-Side Left 068851
17 Filter Assembly X81440
17a Filter-Air-18.28X15.5X.70 052779-15
18 Cover-Access-Front-R. 068844
19 Screw-10X3/8 Slotted Hex 015582
20 Cover-Access-Left 081834
21
Trim-Rear Corner-R 068847
Trim-Rear Corner-L 080238
To Next Page
