Taylor C723 User Manual

4-4
OPERATOR PARTS IDENTIFICATION
Model C723
Operator Parts Identification
4
Model C723 Factory Equipped with Agitator Exploded View Parts Identification
Item Description Part No.
1 Cover-Hopper-14 Qt-Gray 041682-GRY
2 Orifice 022465-100
3 O-ring-3/8 OD X .070W 
(100 to Bag)
016137-SER
4 Tube A.-Feed-SS-5/32 Hole X29429-2
5 O-ring-.643 OD X .077W 
(50 to Bag)
018572-SER
6 Panel-Rear 069340
7 Panel A.-Side Right X68854
8 Panel A.-Front X81843
9 Screw-1/4-20X3/8 SLTD 011694
10 Panel A.-Shelf 
(Includes Items 10a -10c)
X81840
10a Panel A.-Front-Lower X81841
10b Shelf-Drip Tray 080782
Item Description Part No
10c Screw-1/4-20X3/8 SLTD 011694
11 Screw-Wing Head 081582
12 Tray-Drip 080781
13 Shield-Splash-Wire 046177-SP
14 Pan A.-Drip 15 1/8 Long X51601
15 Stud-Nose Cone 055987
16 Panel-Side Left 068851
17 Filter A. X81440
18 Cover-Access-Front-R. 081833
19 Screw-10X3/8 Slotted Hex 015582
20 Cover-Access-Left 081834
21 Agitator 056592-SP
22
Trim-Rear Corner-R 068847
Trim-Rear Corner-L 080238

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
