Models QS12/QS24
Parts
040715
Box A.--Relay (X74036) Parts ID List
ITEM DESCRIPTION PART NO.
1 SCREW-10-32X3/8 TRUSS HD 024298
2 COVER-CONTROL BOX 074002
3 PCB A. -CONTROL X53512-SER
4 BLOCK -TERMINAL-PLUG 6P 040322-002
5 STANDOFF -NYLON 6-32X1L 078635
6 HARNESS -WIRE 074039
7 SCREW-6-32X3/8 BIN. HD 002201
8 BOX A.-CONTROL X74037
9 WASHER-#8 SHAKEPROOF 000964
ITEM DESCRIPTION PART NO.
10 NUT-8-32 HEX 000969
11 SCREW-8-32X5/16RDHDSS 017552
12 BRACKET ’E’ RELAY 074040
13 RELAY 30A -277V-12VDC 074041
14 CONNECTOR-MATE L OK 6 029248
* BUSHING-SNAP 3/8IDX1/20D 091254
* SOCKET-.084 OD/14-20 AWG 021625
* GROUNDING A.-STRAP X74123
*NOT SHOWN
