Taylor QS Series Service Manual

46
Parts
Models QS12/QS24
060102
Heater Elements - Lower Grill
ITEM DESCRIPTION PART NO.
*1 Heater-Cast 079639--
2 Harness-T/C Lower 078643
*
3
Control--Hi Limit -- 475F 078410
*
3
Control--Hi Limit -- 550F (50 hz) 074165
4 Washer 075716
5 Nut-5/16-18 MF Lock 017327
*Specify Electrics when ordering heaters and hi --limit
controls; i.e., unit B.O.M. by serial number.
