Models QS12/QS24
Parts
060102
Upper Platen Assembly Parts ID List
ITEM DESCRIPTION PART NO.
1 Platen A. --Service 208V 4200W X79629--23
1a Screw-10-32 x 3/8 Taptite Hex 039381
1b Screw-10-32 x 3/8 Truss HD SS 024298
1c Cover A.-Platen X78776
Control--Hi Limit -- 475F 078410
1d
Control--Hi Limit -- 550F (50 hz) 074165
1e Bar-Gap Adj. Slide Mounting 078783
1f Screw-1/4-20 x 5/8 MF Hex Cap 017522
1g Screw-10-32 x 3/4 Slot 028641
2 Retainer-Gap Slide 078792
**3 Cover A.-Platen 078799
4 Screw-10-32 x 3/8 Truss HD SS 024298
5 Bar-Adjusting Gap 078779
6 Pin-Locating 5/16-18 078544
7 Washer-Teflon 4.032 ID x 5 OD 078555
8 SlideA.-GapRear X78864-R
9 SlideA.-GapFront X78864-F
10 Screw-1/4-20 x 1/2 Flat HD 078526
ITEM DESCRIPTION PART NO.
11 Nut-10-32 MF Lock 020983
12 Retainer-Platen 078562
13 Bushing-Platen 4.015 ID Flat 078781
14 Block-Anti Rotation 078515
15 Brace A.-Platen Arms X79071
16 Tube-Wire 078493
17 Screw-10-32 x 1/2 MF Hex Cap 020982
18 Strap-Gap Bar 078583
19 Screw-Shoulder 10-32 x 3/4 L 078860
20 Kit A.-T Handle X74326--KIT
20a Washer-11/32 ID x 11/16 OD 078638
21 Pointer-Gap Adj. 078637
22 Label-Product 079714
23 Strap-Gap Adj. 078636
* Harness--Wire--Upper Power 078621
* Thermocouple--LW Front 074178
* Thermocouple--LW Middle 074179
* Thermocouple--LW Rear 074180
* Not shown
** Not part of X78794 Assembly
To Next Page
