Introduction
Models QS12/QS24
Model QS Series Specifications
Electrical
QS12 Electrical Cord Connected
208-240/50/60/3 Tota l Amps Supplied With KW
With Platen 27.0 30 amp cord
NEMA L15-30P
9.6
QS24 Electrical Permanently Connected
208-240/50/60/3 Tota l Amps Requires KW
Flat 30.0 60 amp cord
IEC309-1 & -2
10.8
With one platen 42.0 60 amp cord
IEC309-1 & -2
15.0
With two platens 53.0 60 amp cord
IEC309-1 & -2
19.2
Available in electric only. Other electrical
characteristics are available. (For exact electrical
information, always refer to the data plate of the unit.)
Disconnect Switch
If the unit has no plug, a separate disconnect switch
must be installed, or another alternate means to
disconnect power must be implemented.
Dimensions
QS12 Width: 12” (305 mm)
QS24 Width: 24” (609 mm)
Depth: 35-1/2” (902 mm)
Height: 15-3/8” (391 mm) to the top of the
back splash shield.
20” (508 mm) with the optional
upper platen lowered.
Approximate Weights
QS12 (One Platen)
Net: 265 lbs. (120.2 kgs.)
Crated: 306 lbs. (138.8 kgs.)
12.4 cu. ft. (0.35 cu. m.)
QS24 (Flat)
Net: 210 lbs. (95.3 kgs.)
Crated: 275 lbs. (124.7 kgs.)
QS24 (One Platen)
Net: 305 lbs. (138.3 kgs.)
Crated: 370 lbs. (167.8 kgs.)
QS24 (Two Platens)
Net: 400 lbs. (181.4 kgs.)
Crated: 465 lbs. (210.9 kgs.)
22.0 cu. ft. (0.62 cu. m.)
Air Clearance
These grills require a minimum of 4” (102 mm)
on the bottom of the unit and 3” (76 mm) from the rear
of the unit to allow for adequate air circulation. Failure
to comply with these dimensions will hinder grill
performance and cause damage to its components.
Multiple QS Series grills may be stored side by side.
The QS Series grills must be kept at least 3”
(76 mm) from combustible materials. Failure to comply
will result in a fire hazard.
These units are designed and constructed to meet
stringent safety and sanitation requirements for NSF
and other food service regulatory agencies.
Specifications are subject to change without notice.
