43
Models QS12/QS24
Parts
040715
Pivot A.-Platen Parts ID List
ITEM DESCRIPTION PART NO.
1 Arm-Platen 078520
2 Screw-1/4-20x3/4 SS Truss Hd 078521
3 Handle-Platen Lift 078592
4 Spacer-1-1/2 IDx2-1/8 ODx.005 078524
5 Screw-1/4-20 x 3/8 Allen Set 001801
6 Pivot-Platen Arm 078556
7 Washer-1/4 Shakeproof External 000656
8 Screw-1/4-20x3/4 Hex Hd SS 029823
9 Screw-10-32 x 1/2 MF Hex Cap 020982
10 Bracket-Wire Tube 078538
11 Bearing-Platen Arm Pivot 078541
12 Linkage-Pivot Upper 078760
13 Rod-Platen Linkage Upper 078550
14 E-Ring 1/2 024908
15 Rod-Platen Linkage Mid 078549
16 Bearing-Open End Needle 078522
17 E-Ring 3/8 038958
18 Cap-Bearing Platen Arm 078548
19 Bearing-Open End Needle 078523
20 Bearing-Cylinder Mount 079214
21 Rod-Cylinder Mounting 079195
ITEM DESCRIPTION PART NO.
22 Rod-Linkage 3/4” Diameter 079216
23 E-Ring 3/4 077046
24 Pin-Linkage Arm 078664
25 Plate-Plated Linkage Pivot R 078559
*26 Arm-Platen Linkage 079192
27 Screw--1/4--20--1-1/4 Hex 027798
28 Retainer-Bearing 079191
29 Bearing-Linkage Arm 079213
30 Nut-1/4-20 MF Lock 017523
31 Pivot A.-Platen X78759
32 Mount-Cylinder Lift 079193
** Screw--1/4--20x5/8 MF Hex (4) 017522
33 Bearing-Open End Needle 078652
34 Plate-Plated Linkage Pivot L 078560
35 Screw-1/4-20 x 1-1/4 MF Hex 024351
36 Rod-Platen Linkage Mid 079194
*37 Cylinder--Compressed Gas 074313
38 Bead-Trimlock Edging 029885-325
39 Bracket A.--Cylinder Stop X74272
40 E-- Ring 038958
*Starting with serial number K4024564, 079192 Arm and
074313 Cylinder were replaced with 070453 Arm and
070439 Cylinder. These parts can be installed on
existing units as a pair, NOT independently. Refer to
Service Bulletin #138SG dated 4/26/04.
**Not Shown
To Next Page
