36
Parts
Models QS12/QS24
051128
QS24 Operator Parts Exploded View
1
2
7
6
8
5
3
4
O
N
O
FF
O
N
O
FF
M
EN
U
UF
T
IM
E
TEM
P
UP
D
O
W
N
E
XIT
U
M
U
R
LR
LM
L
F
R
MANU
FA
CTU
R
ED
B
YT
H
ETAY
L
OR
C
OM
PANY
ROCKTON
,
I
LLI
N
O
IS
U
.
S.A.
9
10
ITEM DESCRIPTION PART NO.
1 BAR-RELEASE SHEET 079930
2 SHEET-SEAMED RELEASE 078804
3 SPRING-.438 OD x .046 x 1.75 079704
4 TRAY A.-GREASE X79940-SER
5 SCRAPER-TROUGH 079726
ITEM DESCRIPTION PART NO.
6 SCRAPER-TEFLON WIPER 075887
7 COVER-TOP 079969
8 BRUSH (GAP CLEANER) 074166
9 STANDOFF-FRONT 079289
10 STANDOFF -REAR 079288
To Next Page
