19
Models QS12/QS24
Controls and Systems
Release Material Installation
Note: Release material is used on units with upper
platens only.
Step 1
Lay the release material sheet on the lower plate and
carefully lower the upper platen.
Step 2
Starting with the spring side, slide the straight end of
the release material rod through the front spring,
continue through the hemmed end of the release
sheet, and through the rear spring.
Step 3
Insert the second rod through the opposite hemmed
side of the release material sheet. Grasp both ends of
the rod, pull the release material up and around the
non-spring side of the upper cooking surface and
attach the rod ends to the retaining clips. Turn the rods
so that the hooked end is facing downward.
Step 4
Raise the platen and assure that the release material
sheet fits evenly and snugly on the upper platen.
Rotate the release material sheet on an every other
day basis.
