TC Electronic M350 User Manual

3
TABLE OF CONTENTS
INTRODUCTION
Table of Contents . . . . . . . . . . . . . . . . .3
Introduction . . . . . . . . . . . . . . . . . . . . . .5
Front Panel Overview . . . . . . . . . . . . . .6
Rear Panel Overview . . . . . . . . . . . . . .8
Signal Flow Diagram . . . . . . . . . . . . . .9
Typical M350 Setups . . . . . . . . . . . . .10
BASIC OPERATION
How to Operate the M350
Input/Output Section . . . . . . . . . . . . . .16
The Delay/Effects Engine . . . . . . . . . .18
The Reverb Engine . . . . . . . . . . . . . .20
Store . . . . . . . . . . . . . . . . . . . . . . . . . .21
Recall . . . . . . . . . . . . . . . . . . . . . . . . .21
The Display . . . . . . . . . . . . . . . . . . . .21
Miscellaneous
Factory Presets . . . . . . . . . . . . . . . . .22
MIDI channel . . . . . . . . . . . . . . . . . . .22
Sysex ID . . . . . . . . . . . . . . . . . . . . . . .22
M350 Software . . . . . . . . . . . . . . . . . .22
Routings . . . . . . . . . . . . . . . . . . . . . . .23
EFFECTS
Delay-effects
Dynamic Delay . . . . . . . . . . . . . . . . . .24
Studio Delay . . . . . . . . . . . . . . . . . . . .25
Triplets Delay . . . . . . . . . . . . . . . . . . .25
Soft Delay . . . . . . . . . . . . . . . . . . . . . .25
PingPong Delay . . . . . . . . . . . . . . . . .25
SlapBack Delay . . . . . . . . . . . . . . . . .25
Compressor . . . . . . . . . . . . . . . . . . . .25
De-Esser . . . . . . . . . . . . . . . . . . . . . . .26
Chorus/Flanger . . . . . . . . . . . . . . . . . .26
Phaser . . . . . . . . . . . . . . . . . . . . . . . .27
Tremolo . . . . . . . . . . . . . . . . . . . . . . . .27
Reverbs
Reverb types . . . . . . . . . . . . . . . . . . .28
TC Electronic, Sindalsvej 34, DK-8240 Risskov – tcdk@tcelectronic.com Rev 1.1 – SW – V 1.00English Version
Prod. No: E60505812
APPENDIX
MIDI Implementation Chart . . . . . . . .30
MIDI Continuous Controllers . . . . . . .31
Reset Procedure . . . . . . . . . . . . . . . .31
MIDI Bulk Dump . . . . . . . . . . . . . . . . .31
Technical Specifications . . . . . . . . . . .32

TC Electronic M350 Specifications

Digital Input and Output

sample rates	44.1 kHz (44.1 kHz and 48 kHz @ Digital Input)
processing delay	0.08 ms @ 48 kHz
frequency response DIO	DC to 23.9 kHz ± 0.01 dB @ 48 kHz

Analog Inputs

impedance bal / unbal	21 kOhm / 13 kOhm
max / min input level @ 0 dBFS	+24 dBu / 0 dBu
sensitivity range @ 12 dB headroom	-12 dBu to +12 dBu

Analog Outputs

impedance bal / unbal	40 Ohm / 20 Ohm
max output level	+14 dBu
frequency response	+0/-0.5 dB, 20 Hz to 20 kHz

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

General

dimensions	19" x 1.75" x 4.2" (483 x 44 x 105.6 mm)
weight	3.3 lb. (1.5 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
