Analog Inputs
Connectors:
Input type
Impedance:
Max. Input Level:
Analog Outputs
Connectors:
Max. Output Level:
Output type
Impedance
Sense input impedance
Overall data
D to A Conversion
A to A delay
Dynamic range
THD
Frequency Response
Crosstalk
EMC
Complies with:
17
TECHNICAL SPECIFICATIONS
¼” phone jacks w. mono-sense
Single ended
1 MOhm
16 dBu @ 12V supply
¼” phone jacks w. mono-sense
16 dBu @ 12V supply
Balanced/Single ended w. ground sense
0 Ohm
225 ohm
24 bit, 128 x oversampling bitstream
1.65 ms
106/98 dB, 20 Hz to 20 KHz
@ Input level 16/-2 dBu, not A-Weighted
< -90 dB (0.0032%) @ 1 kHz, I/O Level
16 dBu, Load > 2400 Ohm
+0.1/-0.2 dB, 20 Hz to 20 KHz
< -100 dB, 20 H z to 7 KHz, < -94 dB,
7 kHz to 20 KHz
EN 55103-1 and EN 55103-2 FCC part 15,
Class B, CISPR 22, Class B
Environment
Operating Temperature:
Storage Temperature:
Humidity:
General
Finish:
Dimensions:
Weight:
Mains Voltage
Power Consumption
Warranty Parts and labor
32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
Anodized aluminum front Plated
and painted steel endcaps
130 x130 x 55mm
765 g
100 to 240 VAC, 50 to 60 Hz
(auto-select) AC wall adapter.
AC adapter supplies 12VDC
minimum 0.3A to pedal.
<5 W
1 year
Due to continuous development,
these specifications are subject to change
without notice.
