Specifications
29
EN
Analog Inputs
Connectors Balanced XLR, Input Impedance 1kOhm
Mic Input Sensitivity @ 0dBFS -44dBu to +2dBu
Mic Input Sensitivity @ 12dB headroom -56dBu to -10dBu
EIN @ max. mic amp gain, Rg = 150 Ohm -128dBu
Analog Outputs
Connectors Balanced XLR
Output Impedance 40 Ohm
Output Level @ 0dBFS +2dBu
Input to Output Analog Audio Performance
Dynamic Range, Mic. @ Min gain 20Hz-20kHz *A-weighted >108dB
Dynamic Range, Mic. @ -18dBu sensitivity20Hz - 20kHz > 104dB
THD+ Noise, Mic. @ Min gain <-90dB
Frequency. Response, Max gain
-1.5dB @ 40 Hz, (200Hz to 20 kHz), +0/-0.3 dB
Conversion Characteristics
Sample Rate 48 kHz,
Converter AKM AK4620B
AD / DA Conversion 24 bit, 128x oversampling bitstream
EMC & Safety
Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B,
CISPR 22, Class B
Certified to IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE
#LR108093
Environment
Operating Temperature 32° F to 122° F (0° C to 50° C)
Storage Temperature -22° F to 167° F (-30° C to 70° C)
Humidity Max. 90 % non-condensing
Supplementary
Dimensions 130mm x 132mm x 41mm (5" x 5.25" x 1.5")
Weight 1.5 lb. (0.72 kg)
Warranty Parts and labor 1 year
