Table 5: Technical Data for MFC “R” 600 Volt Models
Model
Number
Load Rating
(HP)
Rated
Line Current
(A)
Capacitor Circuit
Current
(A)
Power Dissipation
(W)
MFC008CR
5
8
2.1
205
MFC010CR
7.5
10
2.1
220
MFC012CR
10
12
2.7
215
MFC020CR
15
20
5.3
320
MFC025CR
20
25
6.3
400
MFC028CR
25
28
7.2
400
MFC035CR
30
35
9.5
435
MFC045CR
40
45
11.6
450
MFC055CR
50
55
14.7
560
MFC065CR
60
65
17.0
725
MFC080CR
75
80
22.0
775
MFC110CR
100
110
28.5
900
MFC130CR
125
130
35.0
925
MFC160CR
150
160
39.0
950
MFC200CR
200
200
52.0
1275
MFC250CR
250
250
64.0
1500
MFC305CR
300
305
78.0
1750
MFC362CR
350
362
94.0
1725
MFC420CR
400
420
110.0
2100
MFC450CR
450
450
119.0
2175
MFC500CR
500
500
127.0
2200
MFC600CR
600
600
154.0
2400
MFC750CR
750
750
192.0
2550
Note: Addition of PQconnect option (“P”) increases watts loss by 10.
