Register Map
Read Parameters:
Table 16 : Network Interface OUTPUT/ Feedback Register Map
Note for metering data including Output Voltage, THVD, Peak Voltage to RMS voltage ratio, Fundamental
Frequency, and Carrier Frequency if data is not available the PQconnect will report a value of 63353 (or
0xFFFF in hex format) to indicate no data is available. The no data available condition is usually trigged by
the filter output voltage being below the minimum fundamental frequency tracking voltage threshold (see
parameter 680).
Parameter Name
I/O Reg
Address
Offset
Direction
Format and
Examples
Description
USER_STATE
10
Input
0 = Initialization
9 = Save current
values to flash
150 = Load
values from
Flash
255 = Restore
Defaults to
Flash
User state parameters
Read only value.
DSP_SW_VER
12
Output
Two 8bit ASCII
Characters
Example:
0x0141 = ASCII
for "A1"
Software revision code
for processor.
Read only value.
DSP_MODEL_NUM
13
Output
301 = Sinewave
Filter
System Model Number
Read only value.
V_LOAD_AB_RMS
50
Output
Volts RMS
4800 = 480.0
VRMSLL
Range: 120 to
690 VRMSLL
65535 (0xFFFF)
= data not
available.
Filter output RMS
voltage phase A-B
Read only value.
V_LOAD_BC_RMS
51
Output
Filter output RMS
voltage phases B-C
Read only value.
V_LOAD_CA_RMS
52
Output
Filter output RMS
voltage phases C-A
Read only value.
V_LOAD_AB_THD
53
Output
% THVD
50 = 5.0%
THVD
65535 (0xFFFF)
= data not
available.
Filter output voltage
THD phase A-B
Read only value.
V_LOAD BC_THD
54
Output
Filter output voltage
THD phase B-C
Read only value.
V_LOAD_CA_THD
55
Output
Filter output voltage
THD phase C-A
Read only value.
V_LOAD_AB_PEAK_RMS_RATIO
60
Output
% PEAK voltage
/RMS voltage
1414 = 141.4%
65535 (0xFFFF)
= data not
Filter output Peak
Voltage to output RMS
voltage ratio A-B
phase
Read only value.
