MFC Kit Instructions 5.0 PQconnect Option
39
V_LOAD_BC_PEAK_RMS_RATIO
61
Output
available.
Filter output Peak
Voltage to output RMS
voltage ratio B-C
phase
Read only value.
V_LOAD_CA_PEAK_RMS_RATIO
62
Output
Filter output Peak
Voltage to output RMS
voltage ratio C-A
phase
Read only value.
V_OUT_FUND_HZ
100
Output
Range 1 to 500
Hz
65535 (0xFFFF)
= data not
available.
Filter output
fundamental frequency
Read only value.
V_IN_CARRIER_HZ
101
Output
Range 1kHz to
16 kHz
65535 (0xFFFF)
= data not
available.
Filter input carrier
frequency. Note due to
widely variable
modulation schemes
and controls of industry
VFDs this value may
not always be
accurate. This is
intended as an
information estimate of
VFD switching
frequency only.
Read only value.
V_OUT_ROT
102
Output
0 =
undetermined
1 = ABC
Rotation
2 = ACB
Rotation
Filter output phase
orientation
Read only value.
T_PCB
103
Output
400 = 40 C°
Filter internal ambient
temperature
Read only value.
