MFC Kit Instructions 5.0 PQconnect Option
40
Read Parameters:
Table 17 : Network Interface OUTPUT/ Feedback Register Map
Parameter Name
I/O Reg
Address
Offset
Direction
Format and
Examples
Description
SYS_POWER_ON
201
Output
0 = Power on
unsuccessful
1 = Power on
successful
Determines if the PCB was
powered on
Read only value.
SYS_INIT_COMPLETE
202
Output
0 = Calibration in
progress
1 = Calibration
complete
Determines the PCB’s initial state
of calibration.
Read only value.
CAP_DEGREDATION_WARNING
205
Output
0 = No warning
Non zero value =
warning
Filter warning
This value is a bit mask where
individual bits are set to indicate a
detection is active. For a
description of bit positions see
Table 15.
Read only value.
DETECTION_STATUS
210
Output
0 = Detection clear
Non zero value =
Detection active
Relay output 1 and 2 status bit
mask
This value is a bit mask where
individual bits are set to indicate a
detection is active. For a
description of bit positions see
Table 15
Read only value.
OUTPUT_RELAY_1_ENABLE_RO
230
Output
For each bit position:
0 = Detection disabled
1 = Detection enabled
Output relay 1 status detection
enable
This value is a bit mask where
individual bits are set/cleared to
enable/disable a specific status
detection. For a description of bit
positions see Table 15
Read only value.
OUTPUT_RELAY_2_ENABLE_RO
240
Output
For each bit position:
0 = Detection disabled
1 = Detection enabled
Output relay 2 status detection
enable
This value is a bit mask where
individual bits are set/cleared to
enable/disable a specific status
detection. For a description of bit
positions see Table 15
Read only value.
TRACE_GO_DONE_RO
251
Output
0 = Data capture
complete
1 = Data capture in
progress
Capture waveform data
Read only value
PARAM_ACCESS_LEVEL_RO
254
Output
0 = User access
1 = Tech access
2 = Factory access
Different access levels available
Read only value.
