MFC Kit Instructions 5.0 PQconnect Option
41
PARAM_STATE
255
Output
0-11, 13-17 =
parameter load, save,
restore, reboot in
progress.
12 = parameter load
complete
Indicates the present state of the
parameter state machine.
Read only value.
SYS_STATE
256
Output
0 = Initial state
1 = Parameter load
2 = Calibration In
Progress
3 = Calibration check
4 = Run Detections
Determines the current state of the
PQconnect
Read only value.
RATED_VOLTAGE_RO
260
Output
4800 = 480.0Vrms
Range = 1200 to 6900
Filter rated voltage
Read only value.
MB_SLAVE_ADDRESS_RO
300
Output
Default = 10
Range 0 to 255
Modbus slave address
Read only value. To change this
value, modify the corresponding
register in the setpoint section
below.
Read only value.
MB_BAUD_RATE_RO
301
Output
960 = 9600 baud rate
3840 = 38400 baud
rate (DEFAULT)
11520 = 115200 baud
rate
Modbus baud rate
Read only value. To change this
value, modify the corresponding
register in the setpoint section
below.
Read only value.
