MFC Kit Instructions 5.0 PQconnect Option
42
Read Parameters:
Table 18: Network Interface OUTPUT / Feedback Register Map
Parameter Name
I/O Reg
Address
Offset
Direction
Format and Examples
Description
MB_PARITY_RO
302
Output
0 = None
1 = Odd
2 = Even (DEFAULT)
Modbus Parity
Read only value. To
change this value, modify
the corresponding register
in the setpoint section
below.
RELAY_INPUT_STATUS
320
Output
1 = Thermal switch opened
Relay input status.
Read only value.
RELAY_INPUT_1_CONFIG_RO
321
Output
0 = Disabled
1 = Thermal Switch (DEFAULT)
Input relay 1 configuration.
View PCB header J7
Read only value.
RELAY_INPUT_2_CONFIG_RO
322
Output
0 = Disabled (DEFAULT)
1 = Thermal Switch
Input relay 2 configuration.
View PCB header J8
Read only value.
SYS_SERIAL_NUM_2_RO
350
Output
Parameter contains UUUU in the
UUUULLLL-NN serial number
format.
Unit serial number upper
16-bit value
Read only value.
SYS_SERIAL_NUM_1_RO
351
Output
Parameter contains LLLL in the
UUUULLLL-NN serial number
format.
Unit serial number lower
16-bit value
Read only value.
SYS_SERIAL_NUM_0_RO
352
Output
Parameter contains NN in the
UUUULLLL- NN serial number
format.
Unit serial number section
- two-digit unit number.
Read only value.
SYS_NULL_STAT
400
Output
0 = Calibration not active
1 = Calibration in progress
System calibration status
Read only value.
SYS_NULL_TMR
401
Output
Range 0 to 3600 seconds
Calibration remaining time
measured in seconds
Read only value.
