Item No. Description Quantity Designator Remarks
48-TAC002-XX0 TACT SWITCH 1 S002
48-TAC002-XX0 TACT SWITCH 1 S003
48-TAC002-XX0 TACT SWITCH 1 S004
48-TAC002-XX0 TACT SWITCH 1 S005
48-TAC002-XX0 TACT SWITCH 1 S006
48-TAC002-XX0 TACT SWITCH 1 S008A
62-227680-0UA BRACKET ABS-KINGFA 606 (UO) 1
62-310430-0HA LED HOLDER (COMMON) 1
64-P30060-104 M/C SCREW 3 X 6 (ZINC) 1 FOR IC401
64-P30060-104 M/C SCREW 3 X 6 (ZINC) 1 FOR IC402
64-P30100-104 M/C SCREW P 3 X 10 1 FOR Q402
64-P30100-104 M/C SCREW P 3 X 10 1 FOR IC301
64-P30100-104 M/C SCREW P 3 X 10 2 FOR IC601
65-Z30050-23M NUT M 3 1 FOR Q402
65-Z30050-23M NUT M 3 1 FOR IC301
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR L412
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR Q402
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR C421
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR C406B
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 9 FOR FBT
66-382330-0B7 RIVET 2.0X3.7X3.5 2 FOR R402
66-382330-0B7 RIVET 2.0X3.7X3.5 2 FOR IC601 HEAT SINK
67-H24249-2M2 HEAT SINK 1 FOR IC402
67-H24249-3M2 HEAT SINK 1 FOR IC401
67-H30752-3A0 HEAT SINK 1 FOR IC301
67-H30752-3A0 HEAT SINK 1 FOR Q402
70-271510-00A SERVICE CARD 1
71-270870-0A9 LABEL 2
90-269080-ZU0 CLEAN COATING TC-131L 14KG/BARREL 0
18-CB0682-JNX RES. C.F. 6.8K OHM 1/6W +/-5% 1 R414
27-PBC152-J0X CAP. P.E 0.0015UF 63V +/-5% 1 C215
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C418
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C900••-•• TO GND
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D302
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D303
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D305
10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% 1 D304
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C310
Colour Television Chassis: M123A
79
12. Part List
