TCL CTR1042

Item No. Description Quantity Designator Remarks
27-PBC152-J0X CAP. P.E 0.0015UF 63V +/-5% 1 C607
27-PBC152-J0X CAP. P.E 0.0015UF 63V +/-5% 1 C608
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q006
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C901
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C902
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J902
25-BFB108-M1X CAP. ELEC 0.1 UF 50V +/-20% 1 C311
13-000040-53P IC 4053 (ANALOG SW) 1 IC901
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R904
18-DB0153-FNX RES. M.F. 15K OHM 1/6W +/-1% 1 R244
18-DB0103-FNX RES. M.F. 10K OHM 1/6W +/-1% 1 R302
18-DB0104-FNX RES. M.F. 100K OHM 1/6W +/-1% 1 R303
18-DB0223-FNX RES. M.F. 22K OHM 1/6W +/-1% 1 R306
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R612
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R613
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R901
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R902
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R920
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R922
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R905
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R923
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R929
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C906
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C903
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C921
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C915
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C916
27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C601
27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C602
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J202
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J023
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J021
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J911
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J919
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J223
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J209
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J921
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J907
Colour Television Chassis: M123A
80
12. Part List
