TCL CTR1042

Item No. Description Quantity Designator Remarks
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J920
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J904
41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J233
41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J903
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J022
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J017
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J301
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J212
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J229
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J917
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J226
41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J227
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R903
40-2111SG-MAD P.C.B. MAIN PCB BD 1
27-ALR113-J0X CAP. M.PP 0.011 UF 1.6KV +/-5% 1 C406B
27-AMQ561-JHX CAP M.PP 560 PF 2KV +/-5% 1 C402
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R921
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R052
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R311
46-33079W-05X PIN BASE *5 TJC3-5A 1 P903
46-33079W-04X PIN BASE *4 TJC3-4A 1 P904
45-SAWF18-590 SAW FILTER F1859 1 Z101
67-H34423-EA0 HEAT SINK 1 FOR IC601
46-35107W-03X PIN BASE EH-3A 1 P001
08-2170SG-PAN ASS'Y- PACKING 1
49-382550-BAT BATTERY R06P AA 1.5V 5# 2
72-2170SG-E031A OPERATION MANUAL 1
74-022032-6WE POLYBAG (23cmX34cmX0.06mm) 1
74-120120-80HAA POLYBAG W/SUFFOCATION WARNING 1
75-2170LL-CC0 POLYFOAM (LL) 1
75-2170LR-CC0 POLYFOAM (LR) 1
75-2170UL-CC0 POLYFOAM (UL) 1
75-2170UR-CC0 POLYFOAM (UR) 1
76-A2170I-0AT CARTON BOX 1
08-2170SG-PWY ASS'Y- POWER BD 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D833
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D802
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D815
Colour Television Chassis: M123A
81
12. Part List
