TCL Air Conditioner Service Manual
3
Technical Specifications
Model No. TAC-07CS/K TAC-07CHS/K TAC-09CS/K TAC-09CHS/K
Type Cooling Only Heating Pump Cooling Only Heating Pump
Control type Remote Remote Remote Remote
Rated cooling capacity Btu/h 7,000 7,000 9,000 9,000
Rated heating capacity Btu/h N/A 7,500 N/A 9,500
EER for cooling Btu/h.w 9.6 9.6 9.6 9.6
COP for heating W/W N/A 2.8 N/A 2.8
Moisture removal Liters/h 0.8 0.8 0.8 0.8
High dB(A) 36 36 36 36
Med. dB(A) 32 32 32 32
Indoor noise level at
cooling
Low dB(A) 29 29 29 29
Outdoor noise level dB(A) 50 50 50 50
Electrical Data
Power supply 220-240V~/50Hz
Voltage Range V 198~264 198~264 198~264 198~264
Cooling A 4.2 4.2 4.2 4.2
Rated current
Heating A N/A 4.1 N/A 4.1
Cooling W 895 895 900 900
Rated input
Heating W N/A 880 N/A 880
Refrigerating System
Refrigerant/Charge Gram R22/700g R22/700g R22/700g R22/700g
Type Rotary Rotary Rotary Rotary
Model ------------------ ----------------- ------------------ ------------------
LRA A ------ ------- ------ ------
Compressor
MFG ----------------- ----------------- ---------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 430 430 430 430
Indoor fan type Cross flow Cross flow Cross flow Cross flow
Cooling rpm 1000/950/900 1000/950/900 1000/950/900 1000/950/900
Heating rpm N/A 970/900/800 N/A 970/900/800
Dry rpm 900 900 900 900
Indoor fan speed
H/M/L
Sleep rpm 650 650 650 650
Indoor fan motor output W 12 12 12 12
Outdoor air circulation m
3
/h --- --- --- ---
Outdoor fan type Propeller fan Propeller fan Propeller fan Propeller fan
Outdoor fan speed rpm 895 895 895 895
Outdoor fan motor output W 31 31 31 31
Connections
Refrigerant coupling Flare type
Gas Inches 5/8 5/8 5/8 5/8
Connecting Pipe
Liquid Inches 7/16 7/16 7/16 7/16
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
12~19 12~19 12~19 12~19
Indoor mm 710×250×179 710×250×179 710×250×179 710×250×179Net dimensions
(W x H x D)
Outdoor mm 600×500×232 600×500×232 600×500×232 600×500×232
Indoor kg 7.5 7.5 7.5 7.5
Net weight
Outdoor kg 25 25 25 25
Indoor mm 805×325×270 805×325×270 805×325×270 805×325×270Packing dimensions
(W x H x D)
Outdoor mm 745×352×542 745×352×542 745×352×542 745×352×542
Indoor kg 10 10 10 10
Gross weight
Outdoor kg 28 29 28 29
Loading Capacity 40’/40’HC 132/280/318 132/280/318 132/280/318 132/280/318
