TCL Air Conditioner Service Manual
2. Product Dimensions
Indoor Unit:
Outdoor Unit:
Model A B C D E F G H I J K
TAC‐09CHSD/XA31I
698 190 255 712 498 234 415 291 225 48.5 52
TAC‐12CHSD/XA31I
777 205 250 712 498 234 415 291 225 48.5 52
TAC‐18CHSD/XA31I
910 205 292 780 605 290 500 360 327.5 55 63
TAC‐24CHSD/XA31I
1010 220 315 845 607 326 586
374.9
347.5
58.6
63
2
