Cooling capacity - 2/5
Case-12
Factor
Cooling capacity downs by bad air flows.
Spacing for the air flows in window type air conditioners.
Troubles &
Causes
Defect Details
Guidelines
■ Ensure not to disturb the air intake flows.
■ Ensure not to disturb the air discharge flows. The
awning is recommended for a optimum cooling.
1. The space for air intake is too narrow.
Closed air intake flow
Closed air
discharge flow
2. The space for air discharge is too narrow.
Air intake holes
30cm
Wall
Wall Wall
Wall
