TCL TAC-12CSA User Manual

TCL Air Conditioner Service Manual
15
WIRING DIAGRAM
MODEL:TAC-07CSA/M TAC-09CSA/M, TAC-12CSA/M
INDOOR UNIT:
Protecter
Fan Motor
Vane Motor
Indoor Unit
Evaporator
YLW/GRN
Brown
Red
Yellow
Blue
YLW/GRN
Display PCB
Pipe Temp. sensor
Room Temp. sensor
Transformer
Power Supply
Brown
Blue
PCB
CN1
CN2
TH1
TH2
P2-1
P5
P4
P2-2
NO
K1
COM
4
3
CN8
CN6
CN5 CN4
CN3
M
M
θ
N
3
2
1
Outdoor
Unit
1
2
3
N
YLW/GRN
Blue
Yellow
Red
Brown
OUTDOOR UNIT
Compressor
Optional Part
YLW/GRN
Fan Capacitor
Capactor
Compressor
Blue
R(M)
YLW/GRN
Blue
ORG
YLW/GRN
Blue
Brown
Blue
Black
White
White(Black)
Blue
Protector
Red
S
C
CM
FM
Fan Motor
Outdoor Unit
Indoor Unit
1
N
N
1

TCL TAC-12CSA Specifications

General

Capacity	1 Ton
Power Supply	220-240V, 50Hz
Type	Split
Operating Temperature (Cooling)	18°C to 43°C
Cooling Capacity	12000 BTU/h
