TCL Air Conditioner Service Manual
19
WIRING DIAGRAM
MODEL:TAC-24CSA/M
INDOOR UNIT:
FM
SM
SM
OUTDOOR UNIT
Compressor
White(Black)
CM
R(M)
S
Red
Blue
Compressor
Capacitor
Protector
C
White
Brown
YLW/GRN
Yellow
Fan Capacitor
FM
Optional Part
Fan Motor
Outdoor Unit
Indoor Unit
Red
Red
Blue
Blue
YLW/GRN
White
White
Blue
White
Blue
YLW/GRN
Brown
Power Supply
Contactor
L
1
N
1
N
L
L
N
