TCL U-MATCH-R32 Series

128
TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
1
25001-000240
Stepper motor
1
2
45008-000217
Air duct support
2
3
45008-000229
Air outlet bottom plate
1
4
45008-000125
Air vent foam component
1
5
45008-000284
Air guide plate
1
6
25001-000123
Stepper motor
1
7
45011-000087
Water tray component
1
8
45801-000062
Blade Assembly
1
9
45013-000127
front panel
1
10
35010-000074
Display components
1
11
95003-004361
Evaporator assembly
1
12
95016-001604
Output tube assembly
1
13
95016-001428
Input tube assembly
1
14
45801-000046
Lower right cover plate assembly of
evaporator
1
15
45801-000074
Evaporator upper right cover plate assembly
1
16
45014-002009
Middle partition component
1
17
45014-003522
Valve plate
1
18
45003-000202
Right side panel assembly
1
19
45014-002001
Right block
1
20
45014-002551
Air intake grille assembly
2
21
45014-003013
Air intake grille assembly
1
22
45006-001403
Electric control box component
1
23
35004-001826
Indoor control panel
1
24
45006-000354
Electric control box cover
1
25
45005-000512
Motor limit card
2
26
45005-000196
Motor bearing right buckle
1
27
25001-000196
Dual axis motor
2
28
45005-000232
Left buckle of motor bearing
2
29
45005-000511
Motor fixing seat
2
30
45008-000195
Wind turbine upper volute
2
31
45009-000015
Centrifugal fan
2
32
45008-000153
Wind turbine lower volute
4
33
45003-000092
Left side panel assembly
4
34
45003-000044
Left block
4
35
45801-000033
Evaporator left cover plate assembly
1
36
45004-000015
Chassis components
1
