TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
3.8.2 Outdoor Units
12K/18K
1
Reserved
7
Compressor crankcase electric heating belt
2
Outdoor temperature sensor
8
Communication line
3
Electronic expansion valve
9
Live wire input
4
Reserved
10
Ground wire
5
DC fan motor output
11
Neutral wire input
6
Four-way valve
24K/30K
