Fig. 8.6 Locations of Rollers (3.5-ton Trucks)
LIFT CYLINDER
OUTER
CHANNEL
INNER
CHANNEL
SIDE ROLLER
CARRIAGE
SLIPPER
END ROLLER
END ROLLER
END ROLLER
END ROLLER
Upper section
Lower section
SIDE ROLLER
