TCM FB20-8 - BATTERY AND CHARGER SYSTEM

- 1 -
1. BATTERY AND CHARGER (OPTION)
The description in this section applies to our optional batteries and chargers. For other types of
batteries and chargers, refer to their respective instruction manuals.
Truck model
Item
FB10-8 FB15-8 FB18-8 FB20-8 FB25-8
Battery
Capacity 330 Ah/5 h 400 Ah/5 h 450 Ah/5 h 565 Ah/5 h
Name VSDX330M VSDX400M VSDX450M VSDX565M
Voltage 48V
Specic gravity of
electrolyte 1.280
Weight
650 kg [1430 lbs] 660 kg [1460 lbs] 930 kg [2050 lbs] 800 kg [1760 lbs] 880 kg [1940 lbs]
Charger
Type On-board type, 3-phase AC semiconstant voltage charger
Rated power 6.0 kVA 8.5 kVA
Rated current 17 A 24 A
Power supply voltage 205 / 390 / 440 V
Applicable battery
capacity 320 - 500 Ah/5 h 450 - 700 Ah/5 h
Output
Voltage 51 - 64 V
Current 80 - 20 A 115 - 29 A
Truck model
Item
FB25-8LB FB25-8V
FB30-8
FB30-8V
FB35-8S
Battery
Capacity 935Ah/5h 865Ah/5h 450Ah/5h
Name VSF935 VSF865 VSDX450MZ
Voltage 48 V 72 V
Specic gravity of
electrolyte 1.280
Weight
1440 kg [3170 lbs] 1325 kg [2920 lbs] 1110 kg [2450 lbs] 1225 kg [2700 lbs]
Charger
Type On-board type, 3-phase AC semiconstant voltage charger
Rated power 12 kVA 12 kVA
Rated current 34 A 34 A
Power supply voltage 205 / 390 / 440 V
Applicable battery
capacity 865 - 935 Ah/5 h 450 - 545 Ah/5 h
Output
Voltage 51 - 64 V 76.5 - 96 V
Current 160 - 40 A 105 - 26 A
