TCS 700-30 - Meter Assembly (Continued)

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 23
Item Description
Qty
700-30 700-35
SP SPA SPD IP IC AF SPA SPD
1 Round Head Screw 6 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279
2 Adjuster Assembly 1 700100 700100 700100 700100 700100 700100 700100 700100
3 Drive Shaft 1 700019 700019 700019 700019 700019 700019 700019 700019
4 E-Ring 1 700016 700016 700016 700016 700016 700016 700016 700016
5 Acetal Face Gear 1 700018 700018 700018 700018 700018 700018 700018 700018
6 Acetal Bushing 2 700020 700020 700020 700020 700020 700020 700020 700020
7 Adjuster Cover Plate 1 700017 700017 700017 700017 700017 700017 700017 700017
8 Seal Wire 1 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849
9 Drilled Head Screw 2 700042 700042 700042 700042 700042 700042 700042 700042
10 Drive Shaft Retainer 1 700022 700022 700022 700022 700022 700022 700022 700022
11 Head Mount Screw 4 700040 700040 700040 700040 700040 700040 700040 700040
12 Register Support 1 700200 700200 700200 700200 700200 700200 700200 700200
13 Packing Retaining Plate 1 700015 700015 700015 700015 700015 700015 700015 700015
14A 2:1 Packing Capsule Assy. 1 700150 700150 700155 700155 700155 700155 700150 700155
14B 1:1 Packing Capsule Assy. 1 700170 700170 700175 700175 700175 700175 700170 700175
15 Packing O-ring 1 700009 700009 700010 700010 700010 700010 700009 700010
16 Plug 2 700024 700024 700024 700024 700024 700024 700024 700024
17 Front Cover 1 703500 703500 703503 703500 703500 703503 703500 703503
18A Cap Screw 16 703016 703016 703016 703016 703016 703016 703016 703016
18B Drilled Cap Screw 4 703016D 703016D 703016D 703016D 703016D 703016D 703016D 703016D
19 Rear Cover 1 703550 703550 703553 703550 703550 703553 703550 703553
20 Round Head Screw 12 702014 702014 702014 702014 702014 702014 702014 702014
21 Bearing Plate 2 703230 703235 703235 703230 703225 703225 703225 703225
22 Cover O-ring 2 703001 703001 703071 703002 703002 703002 703001 703002
23 Housing 1 703110 703110 703113 703110 703110 703113 703110 703113
24 Flat Washer 8 703018 703018 703018 703018 703018 703018 703018 703018
25 Cap Screw 8 703017 703017 703017 703017 703017 703017 703017 703017
26A Flange, 3” NPT 2 703600 703600 703613 703600 703600 703613 703600 703613
26B Flange, 3” BSPT 2 703603 703603 703611 703603 703603 703611 703603 703611
27 Flange O-ring 2 703012 703012 703013 703013 703013 703013 703013 703013
28 Blocking Rotor Gear 1 703351 703351 703351 703350 703350 703350 703351 703351
29 Rotor Lock Nut 3 703010 703010 703010 703010 703010 703010 703010 703010
30 Displacement Rotor Gear 2 703451 703451 703451 703450 703450 703450 703451 703451
31 Rotor Key 3 703008 703008 703008 703008 703008 703008 703008 703008
32 Displacement Rotor 2 703405 703405 703422 703410 703410 703425 703405 703422
33 Blocking Rotor 1 703305 703305 703322 703310 703310 703325 703305 703322
34 Lock Washer 4 700071 700071 700071 700071 700071 700071 700071 700071
700-30 / 700-35 Meter Assembly
Meter Cold Weather Seal Kit—TCS 703078
Contents:
(15) Packing O-Ring Qty. 1
(22) Housing O-ring Qty. 2
(27) Flange O-ring Qty. 2
All seals are low temperature Nitrile Rubber
