TCS 700-30 - Air Eliminator Assembly (Continued)

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 25
730 Air Eliminator Assembly
Item Description Qty
730-20
SP SPD IP AF
1A Cap Screw 8 740050 740050 740050 740050
1B Drilled Cap Screw 4 740050D 740050D 740050D 740050D
2 Ring Washer 12 740051 740051 740051 740051
3A Outlet Cover; NPT 2 740010 740016 740010 740016
3B Outlet Cover; BSPT 2 740710 740716 740710 740716
4 Encapsulated Valve Plate 2 740205 740205 740215 740215
5 Screw 4 740030 740030 740030 740030
6 Split Lock Washer 4 740017
740017 740017 740017
7 Air Eliminator Housing 1 740020 740022 740020 740022
8 Retaining Clip 2 740012 740012 740012 740012
9 PTFE Reed Strip 2 - 740077 740077 740077
10 Float Assembly 1 740013 740013 740013 740013
11 Diffuser & Shaft Assy. 1 740035 740035 740035 740035
11A
Large Hole Diffuser &
Shaft Assy.
1 740095 740095 740095 740095
12A Cap Screw 2 700054 700054 700054 700054
12B Drilled Cap Screw 2 700054D 700054D 700054D 700054D
13 Flat Washer 4 702018 702018 702018 702018
14 Plug 1 2-126146 2-126146 2-126146 2-126146
15 Plate Seal 4 740005
740004 740004 740004
16 Valve Plate 2 740038
740006 740006 740006
17 Valve Plate Kit 2 740138 740106 740106 740106
18 Reed Valve 2 740007 740007 740007 740007
