TCS 700-30 - Hydraulic Preset Valve Assembly (Continued)

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 29
750-30 Hydraulic Preset Valve Assembly
Item Description Qty
750-30
SP IP SPD
1 Linkage Assembly Kit, STD 1 753062KT 753062KT 753062KT
2 Linkage Lock Nut 2 750001 750001 750001
3 Linkage Sleeve 2 750002 750002 750002
4 Linkage Spherical Pivot 1 750003 750003 750003
5 Linkage Arm 1 753062 753062 753062
6 Hex Nut 1 750010 750010 750010
7 Linkage Screw 2 750011 750011 750011
8 Flat Washer 2 68001 68001 68001
9 Preset Bracket 1 753099 753099 753099
10 Locking Nut 1 750012 750012 750012
11 Ball & Stud 1 753053 753053 753053
12 Operating Lever 1 753210 753210 753210
13 Linkage E-Ring 1 750004 750004 750004
14 Cap Screw 1 753002 753002 753002
15 Star Washer 1 753004 753004 753004
16 Hex Nut 1 753005 753005 753005
17 Screw 2 792004 792004 792004
18 Shaft Seal Kit 2 753314KT 753314KT 753314KT
19 Lower Seal 1 753033 753034 753133
20 Piston Guide 1 753031 753031 753031
21 Gasket 1 703022 703022 703022
22 Flat Washer 4 753013 753013 753013
23 Cap Screw, Drilled 2 703027D 703027D 703027D
24 Cap Screw 2 703017 703017 703017
25 Valve Cover 1 753015 753015 753018
26 Shaft 1 753008 753008 753008
27 Lever Arm Shaft 1 753006 753006 753006
28 Spring Pin 1 753022 753022 753022
29 Lever 1 753023 753023 753023
30 Flat Washer 4 753024 753024 753024
31 Cotter Pin 4 753037 753037 753037
32 Swivel Pin 2 753027 753027 753027
33 Internal Valve Spring 1 753019 753019 753019
34 Cover O-Ring 1 753044 753044 753144
35 Piston 1 753020 753020 753020
36 Flat Washer 1 753028 753028 753028
37 Snap Ring 1 753029 753029 753029
38 Valve Body 1 753040 753040 753043
39 Upper Seal 1 753036 753036 753036
40 Side Swing Linkage Arm 1 753001 753001 753001
41 Side Swing Linkage Kit 1 753001KT 753001KT 753001KT
42 Side Swing Preset Bracket 1 750020 750020 750020
43 Rear Swing Linkage Arm 1 753061 753061 753061
44 Rear Swing Linkage Kit 1 753061KT 753061KT 753061KT
45 Lever Knob 1 753052 753052 753052
Valve Cold Weather Seal Kit—TCS 753078 All seals are low temperature Nitrile Rubber, FKM or PTFE
Contents:
(19) Lower Seal Qty. 1 (39) Upper Seal Qty. 1
(14) Flange O-ring Qty. 2 (34) Cover Seal Qty. 1
(*) Shaft Seal Qty. 2 (*) Top Seal Qty. 2
(*) - Items replace components from item 14
