TCS 700-30 - Torque Specifications

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 31
This Torque Chart is for 18-8 Stainless Steel Bolts
**Values can be +/- 10% of value listed**
Torque Specifications
700-30/35 METER ASSEMBLY
Part Number
& Description
Tool
Foot Lbs. Newton Meter
Unlubricated Unlubricated
TCS 703016
Cover Screws
1/2” hex
wrench/socket
5/16-18 UNC 2B 11 6.6 14.9 8.9
TCS 700040
Counter Support
7/16” hex
wrench/socket
1/4-20 UNC 2B 6.3 3.8 8.5 5.2
TCS 702014
Bearing Plate
slotted
screwdriver
10-24 UNC 2B 1.9 1.1 2.6 1.5
TCS 1-128279
Dust Cover
slotted
screwdriver
10-24 UNC-2B 1.9 1.1 2.6 1.5
TCS 703010
Rotor Gear
1-1/16” hex
wrench/socket
3/4-16 124.2 74.5 168.4 101.0
Bolt/Nut Size
Lubricated Lubricated
740-30 AIR ELIMINATOR/STRAINER ASSEMBLY
Part Number
& Description
Tool Bolt/Nut Size
Foot Lbs. Newton Meter
Unlubricated Lubricated Unlubricated Lubricated
TCS 740050
Cover Plate
1/2” hex screw
wrench/socket
5/16-18 UNC 2B 11 6.6 14.9 8.9
TCS 703017
Cap Screws
9/16” hex screw
wrench/socket
1/2-13 UNC 2B 43.1 25.9 58.4 35.1
TCS 740030
Reed & Diffuser
slotted
screwdriver
8-32 UNC 2B 1.65 1.0 2.2 1.4
Part Number
& Description
Tool Bolt/Nut Size
Foot Lbs. Newton Meter
Unlubricated Lubricated Unlubricated Lubricated
TCS 753011
Cover
3/4” hex screw
wrench/socket
1/2-13 UNC 2B 43.1 25.9 58.4 35.1
TCS 753012
Cover
3/4” hex nut
wrench/socket
1/2-13 UNC 2B 43.1 25.9 58.4 35.1
TCS 792004
Guide
1/8”
Allen wrench
10-24 UNC 2B 1.9 1.1 2.6 1.5
750-30 HYDRAULIC PRESET VALVE ASSEMBLY
