TCS 700-30 - Strainer; High Volume Strainer Assembly (Continued)

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 27
720-30 Strainer & 725-30 High Volume Strainer Assembly
Item Description Qty
720-30 725-30
SP SPD IP AF SP
1 Flat Washer 8 703018 703018 703018 703018 703018
2A Cap Screw 2 703017 703017 703017 703017 703017
3 Strainer Cover, Optional 1 740041 740042 740041 740042 740041
4 Top Seal O-ring 1 740009 740019 740019 740019 740009
5 Strainer Housing 1 743021 743023 743021 743023 -
6 Basket Cover, Two 1/2” NPT Ports 1 743055 743256 743055 743256 743055
7 Basket Cover, STD 1 743050 743053 743050 743053 743050
8 Seal Ring 1 743003 743004 743004 743004 743003
9A 0.050 Strainer Basket, STD 1 - - 743005 743005 -
9B 40M Strainer Basket, STD 1 743010 743010 - - 743010
9C 80M Strainer Basket 1 743015 743015 - - 743015
9D 100M Strainer Basket 1 743025 743025 - - 743025
10 Flat Washer 8 - - - - 703018
11A Cap Screw 2 - - - - 703017
12 High Capacity Strainer Housing 1 - - - - 745031
13 Plug 1 - - - - 700024
14 Flange O-ring 1 703012 703013 703013 703013 703012
15 Strainer Adapter 1 - - - - 745038
16 Cap Screw 4 - - - - 745005
17 Foot Mounting Bracket 1 - - - - 745025
18 Ring Washer 4 - - - - 745006
19 Cap Screw 4 - - - - 745005
20 3/8” x 1/2” NPT Thermowell 1 740305 740405 740305 740405 740305
21 1/2” x 1/2” NPT Thermowell 1 740300 740400 740300 740400 740300
22 Basket Cover, One 1/2” NPT Port 1 743155 743156 743155 743156 743155
11B Drilled Cap Screw 2 - - - - 703017D
2B Drilled Cap Screw 2 703017D 703017D 703017D 703017D 703017D
Strainer Cold Weather Seal Kit—TCS 743078 Contents:
All seals are low temperature Nitrile Rubber (4) Top Seal Qty. 1
(8) Seal Ring Qty. 1
(14) Flange O-ring Qty. 2
