TCS 700-30 - Air Check Valve Assembly: 760-30 SP

TCS900003, Rev.6
04/26/2016
Check us out at www.TCSmeters.com!
Page 30
760-30SP Air Check Valve Assembly
Item Description Qty 760-30SP
1 Screw 2 792004
2 Piston Guide 1 793015
3 Piston Guide External Seal 1 793020
4 Piston Guide Internal Seal 1 793023
5 Piston Guide Snap Ring 1 793035
6 Piston 1 793002
7 Spring 1 793001
8 Body Snap Ring 1 793030
9 Housing Seal 1 793025
10A Valve Housing; 1/2” NPT 1 793011
10B Valve Housing; 1/2” BSPT 1 793711
11 Gasket 1 703022
