TCS ISW3030 User Manual

07/2015 5
TCS TürControlSysteme AG, TCS Hotline Germany: +49 (0) 41 94/ 9 88 11 88 Subject to technical changes.
Mail: hotline@tcsag.de ISW3030-0140 UK 2 A
Device overview
Technical data
supply voltage: +24 V ± 8 % (power supply and control unit)
housing: plastics (colors as listed in catalogue)
dimensions (in mm): H 180 x W 100 x D 23
weight 185 g
acceptable ambient temperature: -5 ...+ 40 °C
degree of protection: IP30
input current stand-by 2-wire operation: I(a) = 1 mA
3-wire operation: I(a) = 0.2 mA, I(P) = 0.8 mA
max. input current: I(Pmax) = 75 mA
microphone
call display (green)
display call OFF (red)
call OFF button
light switch button
control key
loudspeaker
door release button
volume control
speech button
