1.3.1 General
1.3.4 Front Panel Outputs option
1.3.3 AC Cables
1.3.2 Serial link cables
1.3 ACCESSORIES
Accessories are delivered with the power supply or separately upon ordering.
Below are listed possible accessories and ordering numbers.
PART No. DESCRIPTION
NL 100 19” rack, 3U height
NL 200 Dual output packing
NL 101 Blank panel for 19” rack
NL 102 Additional instruction manual
PART No. MARKET DESCRIPTION
ZUP/U USA 13A, 125V, unshielded, 2m typ. length, with IEC320 connector on one
(NC301) side and NEMA-5-15P connector the on other side.
ZUP/E Europe 10A, 250V, unshielded, 2m typ. length, with IEC320 connector on one
(NC302) side and INT’L 7 standard VII, dual earthing on the other side.
ZUP/O General 10A, 250V, unshielded, 2m typ. length, with IEC320 connector on one
(NC303) side and unterminated stripped wires on the other side. Use the cable
only with plug approved by the national safety standards of the country
of usage.
ZUP/J Japan 13A, 125V unshielded, 2m typ. length, with IEC320 connector on one
(NC305) side and Japan type plug on other side.
In cases where load connection at the front panel is required, optional Front Panel output Jacks for a
load current of 20A maximum is available. Please note that the power supply height is increased with
this option. Refer to outline drawing (par. 3.12) for details.
ORDER No. DESCRIPTION
ZUP /L 20AFront Panel Output Jacks
Serial link cable, for linking power supplies by RS485 communication is provided with the power supply
according to order. Cable description: 0.5m typ. length, shielded, EIA-568A type plugs, 8 contacts.
Refer to par.5.3.4 , for details.
1.2.7 Cooling and mechanical construction
The Zup series is fan cooled. Upon installation take care to allow free air flow into the power supply via
the front panel and out of the power supply via the rear panel. The ZUP series is contained in a compact,
lightweight package which allows for easy installation and space saving in the application equipment.
